Wirtgen Soil Stabilizer

Machine Profile settings are important for accurate performance of applications, such as AutoTrac.

Items Accessible on the Machine Profile Page:

NOTE: If display detects machine, some information is automatically set by machine control units.

Profile name, machine type, and serial number are displayed on General tab.

Lateral distance (left or right) from the center line of the machine to center of GPS receiver.

In-line distance from center of the non-steering axle on the machine to center of GPS receiver.

NOTE: GPS offset values are automatically set by the machine.

Lateral distance (left or right) from the center line of the machine to center of the working width.

In-line distance from center of the non-steering axle on the machine to where work occurs.

Width of the area worked on a single pass.

NOTE: Work point values are automatically set by the machine.

Select Save button to store settings from all tabs and close Machine Profile application. Selecting Save is not required when switching between tabs.

Default machine profile settings are stored in machine control units. Changes to these settings are stored in the display.

To reset profile to factory defaults, select Reset Profile button.
